Customizable MDF Continuous Press Line 1-40 Mm Final Board Thickness
Fully Automatic 300~1500 Cbm Per Day MDF/HDF Continuous Press Production Line
1. Control system: PLC control with connection to computer (Mitsubishi, Omron, Siemens optional), from infeed to storage, complete lamination offered. This system is stable and is of high automation. Technical parameters can be set, modified and monitored by human-machine interface.
2. Mechanical system : Stable, easy to operate, high efficient and easy for maintenance.
3. Hydraulic system: Top branded valves and pumps are used for this system, with features of high stability, low noise, and no leakage.
Description
The 300~1500m³/day MDF/HDF production line uses raw material through chips preparation, fiber manufacturing, glue dosing system, forming and hot pressing, cooling &trimming and sanding section to make MDF/HDF board. The final size can be 4 x 8, 6 x 8, 6 x 9, 4 x 12, 6 x 12, 6 x 18. The MDF/HDF board has homogeneous structure, smooth surface, good machining specification and manufacture performance. It is the ideal substitute of nature wood.
Summary of process flow
Main technical data
| Item | Unit | Specification |
| Capacity | m³/d | 300~1500 |
| Width of production line | feet | 4,6,7,8,9 |
| Final board thickness | mm | 1~40 |
| Final board width | mm | 915~2800 |
| Final board length | mm | 1830~5490 |
| Press speed | mm/s | Max. 2500 |
Key equipment of production line
