4x8 Feet Continuous Press MDF Medium Density Fiberboard Line

4x8 Feet Continuous Press MDF Medium Density Fiberboard Line

Products - MDF Production Line - MDF Continuous Press
  • Highlight

    4x8 feet Continuous Press

    ,

    Continuous Press MDF

    ,

    Medium Density Fiberboard line

  • Press Speed
    Max. 2500 Mm/s
  • Width Of Production Line
    4,6,7,8,9 Feet
  • Final Board Length
    1830~5490 Mm
  • Capacity
    300~1500 M³/d
  • Final Board Width
    915~2800 Mm
  • Final Board Thickness
    1~40 Mm
  • Place of Origin
    China
  • Brand Name
    SufoTech
  • Minimum Order Quantity
    1
  • Price
    USD+10,000,000.00~20,000,000.00
  • Delivery Time
    10 months
  • Payment Terms
    L/C,T/T

4x8 Feet Continuous Press MDF Medium Density Fiberboard Line

  • 4x8 Feet Continuous Press MDF Medium Density Fiberboard Line
Get Price Contact Now

Efficient Continuous Press Line for MDF Achieving Max. 2500 Mm/s Press Speed



Fully Automatic 300~1500 Cbm Per Day MDF/HDF Continuous Press Production Line

hot press is mainly used to produce two sides decorated board. suitable for laminating melamine paper,wearable paper and balance paper in both sides of HDF board to produce laminate flooring.

1. Aging treatment: The steel used in our lamination machine was after aging treatment, that's make our material more uniform stress.
2. Frame mechanism: The closed frame is strengthened, which will ensure its working accuracy by appropriate design, reinforced mechanical properties and machining each surface.
3. Oil cylinder adopts the advanced sealing technology, cast-steel cylinder body, chill-iron plunger and good machining accuracy,
all of which will extend the working life of cylinder.
4. Adopt PLC control and touch screen. easily set the time and pressure.

Description



The 300~1500m³/day MDF/HDF production line uses raw material through chips preparation, fiber manufacturing, glue dosing system, forming and hot pressing, cooling &trimming and sanding section to make MDF/HDF board. The final size can be 4 x 8, 6 x 8, 6 x 9, 4 x 12, 6 x 12, 6 x 18. The MDF/HDF board has homogeneous structure, smooth surface, good machining specification and manufacture performance. It is the ideal substitute of nature wood.



Summary of process flow



4x8 Feet Continuous Press MDF Medium Density Fiberboard Line 0



  • Chips Preparation Section
  • Fiber Preparation Section
  • Glue Dosing System
  • Drying Section
  • Forming Line
  • Continuous Press System
  • Master Board Handling System
  • Automatic Storage System
  • Sanding and Cut-to-size Section
  • Surface Grading System
  • Automatic Package Section



Main technical data



ItemUnitSpecification
Capacitym³/d300~1500
Width of production linefeet4,6,7,8,9
Final board thicknessmm1~40
Final board widthmm915~2800
Final board lengthmm1830~5490
Press speedmm/sMax. 2500



Key equipment of production line

  • Drum chipper

4x8 Feet Continuous Press MDF Medium Density Fiberboard Line 1

  • Refiner

4x8 Feet Continuous Press MDF Medium Density Fiberboard Line 2

  • Forming line

4x8 Feet Continuous Press MDF Medium Density Fiberboard Line 3

  • Hot press

4x8 Feet Continuous Press MDF Medium Density Fiberboard Line 4

  • Stacking system

4x8 Feet Continuous Press MDF Medium Density Fiberboard Line 5

  • Automatic storage system

4x8 Feet Continuous Press MDF Medium Density Fiberboard Line 6

  • Sanding and cut-to-size line

4x8 Feet Continuous Press MDF Medium Density Fiberboard Line 7
