Wood Industry Mdf Continuous Press Machine 2500mm/S

Wood Industry Mdf Continuous Press Machine 2500mm/S

Products - MDF Production Line - MDF Continuous Press
  • Highlight

    mdf continuous press machine

    ,

    Mdf Continuous Press 2500mm/S

    ,

    Wood Industry Continuous Press

  • Capacity
    300~1500 M³/d
  • Final Board Width
    915~2800 Mm
  • Final Board Thickness
    1~40 Mm
  • Width Of Production Line
    4,6,7,8,9 Feet
  • Final Board Length
    1830~5490 Mm
  • Press Speed
    Max. 2500 Mm/s
  • Place of Origin
    China
  • Brand Name
    SufoTech
  • Minimum Order Quantity
    1
  • Price
    USD+10,000,000.00~20,000,000.00
  • Delivery Time
    10 months
  • Payment Terms
    L/C,T/T

Wood Industry Mdf Continuous Press Machine 2500mm/S

  • Wood Industry Mdf Continuous Press Machine 2500mm/S
Get Price Contact Now

Max. 2500 Mm/s Speed MDF Continuous Press Line 300-1500 M³/d Capacity 9 Feet Width



Fully Automatic 300~1500 Cbm Per Day MDF/HDF Continuous Press Production Line



Description



What is MDF?
Medium-density fibreboard (MDF) is an engineered wood product made by breaking down hardwood or softwood residuals into woodfibres, often in a defibrator, combining it with wax and a resin binder, and forming panels by applying high temperature and pressure. MDF is generally denser than plywood. It is made up of separated fibres, but can be used as a building material similar in application to plywood. It is stronger and much denser than particle board. The name derives from the distinction in densities of fibreboard. Large-scale production of MDF began in the 1980s, in both North America and Europe.



The 300~1500m³/day MDF/HDF production line uses raw material through chips preparation, fiber manufacturing, glue dosing system, forming and hot pressing, cooling &trimming and sanding section to make MDF/HDF board. The final size can be 4 x 8, 6 x 8, 6 x 9, 4 x 12, 6 x 12, 6 x 18. The MDF/HDF board has homogeneous structure, smooth surface, good machining specification and manufacture performance. It is the ideal substitute of nature wood.



Summary of process flow



Wood Industry Mdf Continuous Press Machine 2500mm/S 0



  • Chips Preparation Section
  • Fiber Preparation Section
  • Glue Dosing System
  • Drying Section
  • Forming Line
  • Continuous Press System
  • Master Board Handling System
  • Automatic Storage System
  • Sanding and Cut-to-size Section
  • Surface Grading System
  • Automatic Package Section



Main technical data



Item Unit Specification
Capacity m³/d 300~1500
Width of production line feet 4,6,7,8,9
Final board thickness mm 1~40
Final board width mm 915~2800
Final board length mm 1830~5490
Press speed mm/s Max. 2500



Key equipment of production line

  • Drum chipper

Wood Industry Mdf Continuous Press Machine 2500mm/S 1

  • Refiner

Wood Industry Mdf Continuous Press Machine 2500mm/S 2

  • Forming line

Wood Industry Mdf Continuous Press Machine 2500mm/S 3

  • Hot press

Wood Industry Mdf Continuous Press Machine 2500mm/S 4

  • Stacking system

Wood Industry Mdf Continuous Press Machine 2500mm/S 5

  • Automatic storage system

Wood Industry Mdf Continuous Press Machine 2500mm/S 6

  • Sanding and cut-to-size line

Wood Industry Mdf Continuous Press Machine 2500mm/S 7
